HF-8100 Heavy water jet loom Specification

Nominal Reed Space:150.170.190.210.230.280.300.320.340.360

The Effective Width: 0 - 500 - Mm (Standard);

                                   0 - 700 - Mm(Optional)

The Quantity Of Nozzle: Single Nozzle. Double Nozzle.Three Nozzle. Four Nozzle

Openings Way: Plain.Cam. Dobby.Jacquard

Beating-Up: Centralized Beating Up System, One Time Oil Fill For Life Time Guaranty

Scissors And Feeler: Mechanical Ceramic Scissors;

                                Photoelectric Weft Detector

All Bolts On The Machine: Stainless Steel 304

Wallboard: One Pc Mogher Bboard

Zero Max: Shimpo Japan(Original)

Gear:Tatung.Taiwan

HF8100 centralized beating up system heavy water jet loom is of the following features, including heavy body and new designee centralized beating up system, all possible polyester fabric purpose making, the most stable water jet loom in the market, seamless steel pipe king piece solid frame, vibration & noise reduction temping treated gable never deforms.

This Machines is equipped with centralizedBeating up system One time oil fill, life timeguaranty
